TECHNICAL CHARACTERISTICS |
• Steel frame
6 mm thick, sturdy contruction
• Painted, rectangular tipping steel hopper
• Cast iron gearbox with gears lubricated in oil bath
• AISI 304 stainless steel spreading disc with 6 adjustable
vanes
• AISI 304 stainless steel flow control with 3 adjustable
openings
• Flexible cable 2,5 m. long for remote flow control
• Manual lever to choose spreading zone
• Standard spring agitator
• Filtering grill
• 3 points linkage, 1st, 2nd Cat.
• Cardan shaft L = 800 mm |
|
Code |
Model |
|
S.06.30 |
SLG 600 TURBO JOY |
|
S.06.40 |
SLG 800 TURBO JOY |
|
S.06.50 |
SLG 1000 TURBO JOY |
ACCESSORIES ON REQUEST
|
Code |
Description |
|
A.041 |
Agitator for powdered fertilizer |
|
C.010 |
Spreader trolley "Standard Tray" pitch widh 1,35 metre |
|
C.015 |
Spreader trolley "Standard Tray" with adjustable pitch widh
from 1,2 to1,8 m. |
|
C.018 |
Cardan joint 1400 mm long, suitable for spreader on trailer |
|
K.000 |
Lighting kit |
|
R.030 |
N° 3 small wheels for manual handling when dismounted |
|
T.004 |
Rain proof hopper cover |
|
T.054 |
AISI 304 stainless steel hopper and extended walls, disc
guard, bolts and nuts. Hot galvanized frame |
|
Z.005 |
Hot galvanized hopper |
|
Z.019 |
Hot galvanized hopper and frame |
TECHNICAL DATA
|
|
|
Model |
SLG 600 TURBO JOY |
SLG 800 TURBO JOY |
SLG 1000 TURBO JOY |
|
Spreading system |
Single spinner disc |
|
Moving machine |
Mounted |
|
Hopper volume |
585 litres |
740 litres |
930 litres |
|
Application rate |
3,0 he / h |
|
Overall dimensions ( WxLxH ) |
163 x 126 x 92 cm. |
163 x 126 x 100 cm. |
163 x126 x108 cm. |
|
Machine mass empty |
194 kg |
204 kg |
214 kg |
|
Spreading width |
16 ÷ 20 m. |
|
Minimum power tractor |
50 HP |
55 HP |
80 HP |
|
Cardan shaft revolution |
540 rpm |
|
Suitable fertilizer type |
Chemical granular, powdered, pellet fertilizers |
|
