Bamboo Chopstick (Wari-Bashi) Working machine

¡@

ROUND BAMBOO CROSS CUTTING & SPLITTING MACHINE
CYM-666
Description:
HORSEPOWER 1HP + 1/2 HP
N.W. 165KGS
G.W. 220KGS
MACHINE SIZE (LxWxH) 85"x35"x49"
PACKING SIZE (LxWxH) 90"x40"x54"

¡@

4-SIDE SIZING MACHINE  CYM-667
Description:
HORSEPOWER 3HP
N.W. 135KGS
G.W. 165KGS
MACHINE SIZE (LxWxH) 57"x27"x42"
PACKING SIZE (LxWxH) 79"x32"x51"

¡@

BAMBOO CHOPSTICK (WARI-BASHI) FORMING MACHINE
CYM-668

¡@

Description:
PRODUCTIVITY 80-90PCS/MIN.
HORSEPOWER 1HP+1/8HP
N.W. 150KGS
G.W. 220KGS
MACHINE SIZE (LxWxH) 75"x32"x47"
PACKING SIZE (LxWxH) 78"x39"x59"

¡@

AUTOMATIC BAMBOO CHOPSTICK(WARI-BASHI)SHAVING MACHINE CYM-669A

¡@

Description:
PRODUCTIVITY 90-110PCS/MIN.
HORSEPOWER 1/2HP+1/2HP
N.W. 310KGS
G.W. 400KGS
MACHINE SIZE (LxWxH) 55"x36"x48"
PACKING SIZE (LxWxH) 60"x41"x59"

¡@

AUTOMATIC BAMBOO CHOPSTICK(WARI-BASHI)SHAVING MACHINE CYM-669B

¡@

Description:
SPINDLE SPEED 3000R.P.M.
HORSEPOWER 1/2 HP
N.W. 50KGS
G.W. 60KGS
MACHINE SIZE (LxWxH) 28"x15"x22"
PACKING SIZE (LxWxH) 33"x20"x32"

¡@

DRYER  CYM-083L

 ¡@
By burning Bamboo or Wood waste, this machine can produce vaporized firepower to dry Bamboo & Wood Ware. The hot air temperature is kept at 10oC to 75oC.

CAPACITY OF WORKING TANK 300000-400000 PAIRS
HORSEPOWER 3HP
N.W. 1000KGS
G.W. 1150KGS
MACHINE SIZE (LxWxH) 77"x39"x86"
PACKING SIZE (LxWxH) 83"x45"x92"



¡@

HEXAGON SHAPE POLISHING MACHINE CYM-651
Description:
CAPACITY OF WORKING TANK 17CUFT
R.P.M. 20
HORSEPOWER 1/2HP
N.W. 180KGS
G.W. 240KGS
MACHINE SIZE (LxWxH) 57"x42"x47"
PACKING SIZE (LxWxH) 63"x47"x59"

¡@

AUTOMATIC CHOPSTICK PACKING MACHINE
CYM-045


FEATURES:
1.Having 2-color printing device.
2.With equipment calculating accurately & automatic, stopping, and Turn-to Zero.
3.To complete printing, filling in & packing at a time. Each machine is operated by just one person.
4.Packing speed is non-sectional shift speed, the speed can be adjusted freely.

TYPE CYM-045
Materials Simile Paper
Width of Paper 60-70 mm
Length of Packing 250-280mm
Productivity 100-130 pcs/min.
Electric Heating 100w
Hores Power 1/2 HP
N.W. 320 KGS.
G.W. 380 KGS.
Machine Size (LxWxH) 74"X31"X72"
Packing Size (LxWxH) 85"X36"X64"

¡@

Specification are subject to change without notice for improvement

¡@

¡@
