TECHNICAL CHARACTERISTICS |
• Hot galvanized, steel frame 6 mm thick, sturdy contruction
• AISI 304 stainless steel tipping hopper and disc guard
• Cast iron gear boxes with gears lubricated in oil bath
• N°2 Spreading discs with 4 stainless steel AISI 304 adjustable
vanes
• AISI 304 stainles steel flow control with 3 adjustable
openings
• Hot galvanized filtering grill
• Standard spring agitators
• 3 points linkage, 1st, 2nd Cat.
• Cardan shaft L = 800 mm |
|
Code |
Model |
|
S.19.01 |
SPW 600 INOX |
|
S.19.10 |
SPW 800 INOX |
|
S.19.20 |
SPW 1000 INOX |
ACCESSORIES ON REQUEST
|
Code |
Description |
|
C.010 |
Spreader trolley "Standard Tray" pitch widh 1,35 metre |
|
C.015 |
Spreader trolley "Standard Tray" with adjustable pitch widh
from 1,2 to1,8 m. |
|
C.018 |
Cardan joint 1400 mm long, suitable for spreader on trailer |
|
C.043 |
AISI 304 stainless steel double conveyor for localized
fertilization on 2 rows |
|
F.006 |
Double flexible cable L = 2,5 m. for remote control |
|
I.003 |
Double hydraulic opening |
|
K.000 |
Lighting kit |
|
R.033 |
N° 3 small wheels for manual handling when dismounted |
|
T.004 |
Rain proof hopper cover |
TECHNICAL DATA
|
|
|
Model |
SPW 600 INOX |
SPW 800 INOX |
SPW 1000 INOX |
|
Spreading system |
Double spinner disc |
|
Moving machine |
Mounted |
|
Hopper volume |
605 litres |
790 litres |
985 litres |
|
Application rate |
3,5 he / h |
|
Overall dimensions ( WxLxH ) |
163 x 126 x 96 cm. |
163 x126 x104 cm. |
163 x126 x112 cm. |
|
Machine mass empty |
176 kg |
184 kg |
200 kg |
|
Spreading width |
16 ÷ 24 m. |
|
Minimum power tractor |
50 HP |
55 HP |
80 HP |
|
Cardan shaft revolution |
540 rpm |
|
Suitable fertilizer type |
Chemical granular, powdered, pellet fertilizers |
|
