水冷 (水平式&單缸)柴油機
|
|
Direct
Fuel Injection Produces Dynamic Power Combustion power acts directly on the toroidal piston crown, boosting energy, decreasing thermal lossesl. Extra high output creates the tough torque needed for heavy duty jobs.
|
|
|
Direct
Fuel Injection Plus Bosch Pump Adds To Fuel savings. The ideal combination of a Bosch pump with hole*valve type injection nozzle and toroidal-shaped combustion chamber provides superior firing performance and enviably swift and certain starting Boschs fuel injection pump uses no compound sections for fuel regulation , which reduces wear and dust accumulation. High-pressure Bosch fuel injection performs instantaneously to increase thermal efficiency by eliminating afterburning.
|
|
|
Longer Continuous Operation Than Other Engines With 20% Larger Fuel Tanks. “One Touch”Air Venting From The Fuel System. |
|
|
The Unique Vibration-Proof Rubber. Due to these low vibration levels, F engines are the best for use in utility vehicles such as tillers or transportation and agricultural wagons. F engines are also suitable for stationary machines, including pumps. |
|
|
Direct
Fuel Injection Produces Dynamic Power Combustion power acts directly on the toroidal piston crown,boosting energy, decreasing thermal lossesl. Extra high output creates the tough torque needed for heavy duty jobs.
|
|
|
Durability of Chen Yu Direct Fuel Injection System enhanced by the heat-proof Insulator for the fuel injection valve. The fuel injection valve is weapped in heat-proof Teflon. This improves the durability of the valve and makes it superior to those of other makers.
|
規格
SPECIFICATIONS
|
型號Model |
cy60F |
cy70F |
|
|
類型Type |
臥式、水冷、四行程循環柴油機 zontal
diedel engine
|
||
|
燃燒系統 Combustion
system |
直接噴射
Direct injection |
||
|
汽缸數 No.of
cylinders |
1 |
||
|
缸徑x行程 Bore x stroke
mm(inch) |
75x80(2.95x3.15) |
78x80(3.07x3.15) |
|
|
排量 Displacement
L(US gal) |
0.353(0.093) |
0.382(0.101) |
|
|
額定連續輸出功率
hp/rpm Rsted cont output
(kw) |
200C |
5.5/2400(4.1) |
6.5/2400(4.8) |
|
270C |
5.0/2400(3.7) |
6.0/2400(4.5) |
|
|
1小時額定連續輸出功率
hp/rpm At 1-hr. rated output
(kw) |
200C |
6.5/2400(4.8) |
7.5/2400(5.6) |
|
270C |
6.0/2400(4.5) |
7.0/2400(5.2) |
|
|
壓縮比
Compression ratio |
17.9 |
18.1 |
|
|
適用之燃油
Applicable fuel oil |
柴油 |
||
|
燃料噴射
Fuel injection pump |
波許型 |
||
|
噴油正時
Injection timeing
deg. |
BTDC19.0 |
||
|
噴油壓力幫
Injection pressure
kg/cm2(psi) |
200(2884) |
||
|
燃油箱容量
F.O.tank capacity
L(US gal) |
7.1(1.88) |
7.1(1.88) |
|
|
潤滑系統
Lubrication system |
帶旋輪線幫和液壓調節閥之充分密封強制潤滑方式
Fored lubrication |
||
|
潤滑油容量有效/油底殼 Lubricating oil capacity(oil
pan) L(US
gal) |
0.6/1.8(0.16/0.48) |
0.6/1.8(0.16/0.48) |
|
|
冷卻系統 Cooling
system |
散熱器 Radiator |
散熱器 Radiator |
|
|
冷卻水容量
Cooling water capacity L(US
gal) |
1.25(0.33) |
1.25(0.33) |
|
|
啟動系統
Starting system |
手動或電動
Hand or Electric |
||
|
發動機淨重
Engine dry weight
kg(ibs) |
68(149.9) |
68(149.9) |
|
