Single Cylinder-Diesel Engine ( Water Cooled )

CY190(R)



Direct Fuel Injection Produces Dynamic Power

Combustion power acts directly on the toroidal piston crown, boosting energy, decreasing thermal lossesl. Extra high output creates the tough torque needed for heavy duty jobs.



Direct Fuel Injection Plus Bosch Pump Adds To Fuel savings.

The ideal combination of a Bosch pump with hole*valve type injection nozzle and toroidal-shaped combustion chamber provides superior firing performance and enviably swift and certain starting Boschs fuel injection pump uses no compound sections for fuel regulation , which reduces wear and dust accumulation. High-pressure Bosch fuel injection performs instantaneously to increase thermal efficiency by eliminating afterburning.





Longer Continuous Operation Than Other Engines With 20% Larger Fuel Tanks. One TouchAir Venting From The Fuel System.



The Unique Vibration-Proof Rubber. Due to these low vibration levels, F engines are the best for use in utility vehicles such as tillers or transportation and agricultural wagons. F engines are also suitable for stationary machines, including pumps.



Direct Fuel Injection Produces Dynamic Power

Combustion power acts directly on the toroidal piston crown,boosting energy, decreasing thermal lossesl. Extra high output creates the tough torque needed for heavy duty jobs.



Durability of Chen Yu Direct Fuel Injection System enhanced by the heat-proof Insulator for the fuel injection valve.

The fuel injection valve is weapped in heat-proof Teflon. This improves the durability of the valve and makes it superior to those of other makers.











規格 SPECIFICATIONS

模型 Model

cy190

cy190R

cy190RE

種類   Type

四衝程臥式柴油引擎

燃燒系統  Combustion system

直接噴射  Direct injection

汽缸數  No.of cylinders

1

孔徑x行程                        毫米()

Bore x strok                      mm(inch)

110x106

(4.33x4.17)

排氣量   Displacement

1.007(0.266)

額定連續輸出功率           馬力/轉速(千瓦)

Rated cont output            hp/rpm(kw)

16.0/220(11.8)

1小時額定連續輸出功率     馬力/轉速(千瓦)

At 1-hr. rated output            hp/rpm(kw)

19.0/2200(14.0)

壓縮比  Compression ratio

16.3

使用之燃油  Applicable fuel oil

柴油

燃料噴射幫浦  Fuel injection pump

BOACH TYPE

噴油正時

Injection timeing                       deg

BTDC 19.0

噴油壓力                公斤/厘米2(/2)

Injection pressure                kg/cm2(psi)

200~210

燃油槽容量                公升(美制加崙)

F.O.tank capacity                 /(U.S. gal)

16.6

(4.39)

13.7(3.62)

潤滑系統  Lubrication system

強制潤滑  Fored Iubrication

潤滑油容量(油盆)           公升(美制加崙)

Lubricating oil capacity(oil pan)     /(U.S. gal)

3.4(0.90)

冷卻系統  Cooling system

熨斗 Hopper

散熱器 Radiator

冷卻水容量                公升(美制加崙)

Cooling water capacity            /(U.S. gal)

17.0

(4.49)

4.0

(1.06)

啟動系統 Starting system

手動 Hand

電動 Electric

引擎淨重                         公斤()

Engine dry weight                   kg(ibs)

181.0

(399.0)

182.0

(401.2)

191.0

(421.1)
